Red J&M front fold grain cart pulled by a red tractor in a harvested field

Front Fold Grain Carts

Grain Carts

Description

Designed with the operator in mind, the upper auger is positioned in the corner and extends toward the tractor cab, creating a closer, clearer view when unloading grain. It provides 100% visibility during unloading AND equally important 100% visibility during the folding sequence.

Made with heavy duty components
Excellent cleanout

Front Fold Grain Carts

Front Fold Grain Carts: J&M’s unique front-folding auger design provides total visibility for a clearer, closer view when unloading grain. Unlike competitors, J&M’s auger design ensures full visibility during both unloading and folding sequences.

Hydraulic Flow Control Spout: Easily correct auger position from inside the tractor cab for efficient and precise grain transfer.

Maximum Auger Reach: Designed for optimal upward, outward, and forward extension, ensuring easier and more efficient grain unloading.

Excellent Cleanout: J&M grain carts excel in cleanout, even with high-moisture grain, thanks to a sump design that prevents bridging.

Standard Features

Computer Balanced Auger: Super-Edge Flighting balanced to within one ounce for a quiet, smooth-running system that extends auger life and reduces vibration.Patented Super-Edge design adds extra material at critical wear points, increasing durability and longevity.

Balanced Tongue Weight: Optimized undercarriage axle positioning provides a properly balanced tongue weight, reducing stress on the tractor draw bar.

V-Truss Axle: Heavy-duty tubular steel with a reinforced V-Truss design prevents bending and twisting, extending the life of your grain cart.

Heavy-Duty Components: Built with high-quality, heavy-duty components to withstand extreme conditions and provide years of reliable performance.

Miscellaneous Standard Features: Includes graphite-coated interior for efficient unload, hydraulic hose and electric cable organizer, bolt-on bottom tang hitch, balanced tongue weight, and jack stand assembly.

Options

Swivel Ball Hitch: Tight articulation eliminates grain cart “slam,” reducing shock loads on the tractor and grain cart for smoother operation.

Increased Hitch Longevity
Industry-Leading 45° Articulation
Easy Maintenance: Protected grease zerks inside the hitch ring and a removable ball with a simple half-turn rotation for quick servicing.

Scale Options: Accurately track crops, safely load semis, and document crop sharing and insurance records for improved planning and cost savings.

Scale Add-on Options: Includes Auto-Gate Shut-Off Kit, Thermal Printer, Moisture Sensor Kit, and J&M iFarm System compatibility.

Patriotic Farmer Edition: Upgrade with an American flag stripe, with proceeds benefiting nonprofit organizations supporting farm families and veterans.

Roll Tarp Kit: Protect commodities from weather with an 18 oz. roll tarp featuring Glide Right tracking and optional electric operation.

LCD Camera Kit: Enhances visibility for safer transport, grain receiving, and unloading.

Hydraulic Drive Kits: For tractors without a PTO, choose between 19 or 21 cu. in. motors to power the grain cart.

Miscellaneous Options: 1⅜"-21 Spline PTO replacement, safety chain for grain cart, and additional customization options.

Specifications

SPECIFICATIONS
Model	525	620	750	875	1000
Vertical Auger	14"	14"	18"	18"	20"
Unload Rate	185+ bu/min	185+ bu/min	400+ bu/min	400+ bu/min	500+ bu/min
SINGLE WHEELS
Capacity	525 Bushels	620 Bushels	750 Bushels	875 Bushels	1,025 Bushels
Wheels (2)	21×32 or 27×32	21×32 or 27×32	21×32, 27×32 or 18×42	21×32, 27×32 or 30×32	30×32, 31×32, 32×36 or 44×32
Tires (2)	24.5×32, 30.5×32 or IF800/60R32	24.5×32, 30.5×32 or IF800/60R32	24.5×32, 30.5×32, IF800/60R32, IF520/85R42 or 520/85R42	24.5×32, 30.5×32, IF800/60R32 or 900/60R32	900/60R32, 35.5×32, 1050/50R32 or IF1250/50R32
Hubs (2)	10 Bolt	10 Bolt	10 Bolt	10 Bolt	10 Bolt
Spindles (2)	4½" Diameter	4½" Diameter	4½" Diameter	4½" Diameter	4½" Diameter
Tongue Weight
Empty	950 lbs	1,000 lbs	1,150 lbs	1,275 lbs	2,900 lbs
Loaded	1,950 lbs	2,100 lbs	2,850 lbs	3,800 lbs	4,200 lbs
Total Weight (approx.)	7,034 lbs	7,330 lbs	9,606 lbs	10,186 lbs	14,078 lbs

A	10'-4"	10'-11"	10'-11"	11'-3"	11'-0"
B	10'-0"	11'-9"	11'-9"	11'-9"	11'-9"
D	7'-6"	7'-6"	7'-3"	7'-2"	6'-2"
F	7'-4"	7'-4"	7'-3"	7'-4"	6'-7"
G	10'-0"	10'-0"	10'-0"	10'-0"	10'-0"
H	12'-8"	12'-8"	12'-9"	12'-8"	13'-5"
I	15'-6"	15'-6"	15'-7"	15'-7"	16'-7"
J	13'-1"	13'-1"	12'-6"	12'-6"	12'-11"
K	0'-10"	0'-10"	0'-5"	0'-9"	0'-5"
L	2'-1"	2'-1"	1'-8"	1'-10"	1'-7"
M	12'-9"	12'-9"	13'-10"	14'-7"	18'-4"
N	17'-11"	17'-11"	20'-1"	22'-0"	29'-1"
O	1'-6"	1'-6"	1'-4"	1'-5"	1'-5"
P	12'-0"	13'-2"	14'-0"	16'-0"	22'-0"
Q	10'-10"	11'-5"	11'-4"	11'-8"	12'-2"
Max Tarp Height	11'-4"	11'-11"	11'-10"	12'-2"	12'-8"
Compaction Rate
24.5x32 Lug (12 ply)	20	24	29	N/A	N/A
24.5x32 Diamond (12 ply)	21	24	30	N/A	N/A
24.5x32 Diamond (16 ply)	N/A	N/A	N/A	35	N/A
IF520/85R42 Lug (169 LI)	N/A	N/A	30	N/A	N/A
520/85R42 Lug (169 LI)	N/A	N/A	33	N/A	N/A
30.5x32 Lug (16 ply)	17	20	25	28	N/A
30.5x32 Lug (18 ply)	16	19	23	26	N/A
IF800/60R32 Diamond (181B LI)	16	19	23	26	N/A
900/60R32 Lug (176 LI Firestone)	N/A	N/A	21	23	28
900/60R32 Lug (176 LI Alliance)	N/A	N/A	20	22	27
35.5x32 Diamond (20 ply)	N/A	N/A	N/A	N/A	26
1050/50R32 Lug (185 LI)	N/A	N/A	N/A	N/A	24
IF1250/50R32 Lug (195 LI)	N/A	N/A	N/A	N/A	18
